Description

The Foxeer F722 V4 FC ICM42688 DPS310 delivers uncompromising flight control performance with a powerful STM32F722 processor, ultra-responsive ICM42688 gyro, and precise DPS310 barometer, ensuring smooth, accurate, and stable flights even in demanding conditions. Designed for advanced FPV pilots, it features robust BEC outputs, ample UARTs, blackbox logging, and reliable 4–6S support, making it a versatile and dependable core for high-performance drone builds.

Specifications

• Model: F722 V4
• CPU: STM32F722RET6
• Barometer: DPS310
• Gyroscope: ICM42688
• Power Input: 4–6S LiPo (14V–28V)
• BEC Output: 5V/3A; 12V/3A
• OSD: Betaflight OSD
• Blackbox: 16MB Flash Memory
• UART: 6 Sets
• ESC Telemetry: RX4
• Buzzer: Yes
• SmartAudio: Yes
• LED: 1 Set 2812 LED
• USB: Type-C
• Firmware: Betaflight (FOXEERF722V4)
• Size: 37 × 37 mm
• Mounting Hole: 30.5 × 30.5 mm, Φ4 mm
• Weight: 8g
• Working Temperature: -20°C to +55°C
• Working Humidity: 20%–95%
• Storage Temperature: -20°C to +70°C
• Package Includes: 1× FC, 4× Rubber Columns

Package Includes

• 1 x Foxeer F722 V4 FC ICM42688 DPS310
