Description

The Foxeer M10Q 120 V2 GPS delivers lightning-fast satellite acquisition and rock-solid positioning with its advanced 10th generation M10 chip, ensuring ultra-precise navigation for demanding FPV pilots and long-range missions. Engineered with multi-constellation support, high sensitivity, and compact durability, it guarantees reliable performance, accurate tracking, and seamless integration for consistent flight confidence in any outdoor environment.

Specifications

• Chip: M10 (10th Generation)
• Frequency Bands: GPS L1, GLONASS L1, BDS B1, GALILEO, SBAS L1, QZSS L1
• Input Voltage: 5V
• Antenna: Ceramic Antenna
• Channels: 72
• Battery: Built-in
• Compass: IST8310
• Compass Orientation: Plug forward, antenna up (BF: CW 90° Flip)
• Baud Rate: 115200bps
• Protocol: Dual NMEA / UBLOX
• Output Frequency: 1Hz–10Hz (default 10Hz)
• Speed Accuracy: 0.05 m/s
• Position Accuracy: 2D ACC 1.5m (outdoor)
• Receiver Sensitivity: Tracking -166dBm, Capture -160dBm
• Max Altitude: 50,000m
• Max Speed: 500m/s
• Max Acceleration: 4G
• Operating Temperature: -40°C to +85°C
• Storage Temperature: -40°C to +105°C
• Weight: 2.7g
• Dimensions: 12.5 × 17 × 5 mm

Package Includes

• 1 x Foxeer M10Q 120 V2 GPS
