Description

The Foxeer M10Q 250 V2 GPS delivers ultra-fast satellite acquisition and rock-solid positioning accuracy, empowering your drone with reliable navigation, smooth return-to-home, and consistent flight data even in challenging environments. Featuring a high-performance 10th generation M10 chip, multi-constellation support, integrated compass, and compact lightweight design, it ensures precise tracking, fast updates, and dependable performance for freestyle, long-range, and cinematic pilots who demand accuracy and efficiency in all demanding flight conditions.

Specifications

• Chip: M10 (10th Generation)
• Frequency: GPS L1, GLONASS L1, BDS B1, GALILEO, SBAS L1, QZSS L1
• Input Voltage: 5V
• Antenna: Ceramic Antenna
• Channels: 72
• Battery: Built-in
• Compass: IST8310
• Compass Orientation: Plug facing forward, antenna up (BF: CW 180° flip)
• Baud Rate: 115200bps
• Protocol: Dual NMEA / UBLOX
• Output Frequency: 1Hz–10Hz (default 10Hz)
• Speed Accuracy: 0.05 m/s
• Horizontal Positioning Accuracy: 1.5m (2D, outdoor)
• Receiver Sensitivity: Trace -166dBm; Capture -160dBm
• Max Altitude: 50,000m
• Max Speed: 500m/s
• Max Acceleration: 4G
• Operating Temperature: -40°C to +85°C
• Storage Temperature: -40°C to +105°C
• Weight: 12g
• Dimensions: 25 × 25 × 8 mm

Package Includes

• 1 x Foxeer M10Q 250 V2 GPS
