Description
The GepRC Cinebot25 S Analog Quadcopter BNF ExpressLRS offers unrivaled stability and exceptional video quality, perfect for aerial footage. Its innovative design, powerful motors, and shock-absorbing features ensure smooth, high-performance filming, while its compact size and lightweight frame enhance its durability and versatility.
Features:
- Integrated external design. Equipped with reinforced carbon plate and modified material for one-piece injection molding at the bottom.
- The shock-absorbing protection cover of the camera provides better stability for footage shooting.
- Two power versions are available: the regular one with SPEEDX2 1404 motor and the superior one with SPEEDX2 1505 motor.
- The TYPE-C and BOOT button on the rear makes parameter adjustment convenient.
- Optimized silicone T-shaped antenna fixing component.
- Cinebot25 Lite quadcopter eqquiped with a LiHV 4S 720mAh battery that weighs less than 250g.
- Equipped with the new TAKER G4 45A 8Bit AIO, the G4 main controller ensures stable flight computations, while its integrated 8Bit 45A ESC boasts robust over-current capability.
- The compatibility between O3 VTX and Cabinet makes the installation of memory cards and footage loading easier.
- The customized fixing stand of the receiver simplifies the internal space.
- Diversify the selectivity of the battery with the comprehensive fixing method of aluminum components and straps.
Specifications:
-
Model: Cinebot25 S Analog Quadcopter
-
Frame: GEP-CT25 Black
-
Wheelbase: 115mm
-
FC: TAKER G4 45A AIO
-
FC firmware: TAKERG4AIO
-
ESC: 45A 8Bit ESC
-
Motor: SPEEDX2 1505 4300KV
-
Propellers:Â HQprop DT63mm x4
-
Connector: XT30
-
VTX: RAD mini 5.8G 1W
-
Camera: CADDX Ratel 2
-
Antenna: Peano 5.8G RHCP UFL
-
Receiver: ELRS2.4G
-
Weight: Cinebot25 S Analog PNP version 170g+1g
-
Recommended battery: LiHV 4S 660mAh-720mAh
-
Flight Time:5′-8’(The reference time is based on low-speed flight. The actual time depends on individuals’ flying methods. )
Package Includes:
- 1 x Cinebot25 quadcopter
- 1 x HQprop DT63mmx4 propeller(pack)
- 2 x Battery anti-slip pads
- 1 x 15150mm battery strap
- 1 x 15*180mm battery strap
- 1 x Naked GoPro base
- 1 x Reserved screw pack
- 1 x L-shaped screwdriver 1.5mm
- 1 x Frequency paring pointer
- 1 x Damping ball puncher
Recommended Spares (Not Included)
- Frame Kit: GepRC GEP-CT25 Cinebot25 Frame (2 Colours)
- Motor: GepRC SPEEDX2 1505 4300KV Motor (Cinebot25 S)
- AIO: GepRC TAKER G4 45A 8Bit AIO
- Prop Guard Spare: GepRC CT25 Propeller Guard Frame Parts – Black
- Props: Gemfan D63 Ducted 63mm (2.5″) Propellers (Set of 4)
- Alternate Props: HQProp DT63MMX3 V2 Poly Carbonate Propeller (Grey)
- Battery options:
