iFlight Protek35 V1.4 3.5″ 6S CineWhoop PNP – Choose Rx

Description

This version is for PNP choose your RX, BNF ExpressLRS model here

The Protek CineWhoop has a longer flight experience and weighs less than the previous cinewhoops! The new version of Protek35 has been released, featuring the Secured Battery Plug function.

iFlight was able to increase the speed and thrust by 50% compared to its 3-inch predecessor which gives a lot more room for a lot more fun; as a result, the ProTek35 is equipped with the Butter Smooth 2205 2300KV Motors. It also features the RaceCam R1 Mini FPV Camera, BLITZ whoop F7 AIO, 55A 2-6S ESC, 5.8GHz BLITZ Mini 600mW VTX,  Nazgul 3535 propellers, and more!

Features:

• No Props or frame in view!
• Secured Battery Plug and CNC bracket – Easy to install battery straps
• High-performance True-AIO Board BLITZ F7 AIO 55A to save weight and space
• T700 Quality Carbon – 40% more tensile strength compared to common 3K carbon
• Lightweight one-piece frame design – Less flexibility, more Rigid, more Durable
• Low Resonance frame construction – Less Jello, more Cinematic footage
• RaceCam R1 Mini FPV Camera 19*19
• Pre-tuned with smooth freestyle settings

Changelog:

2023-08 Significant update to V1.4, frame and component updates.

Tips:

VTX is set to 25mW by default!

Specifications:

• Product Name：ProTek35 V1.4 6S Analog
• AIO: BLITZ Whoop F7 AIO
• Video Transmission: BLITZ Mini 600mW VTX
• Frame: 151mm wheelbase
• Motor: XING 2205 motors
• Prop: Nazgul 3535 propellers
• Takeoff Weight：Approx. 216g (Without Battery)
• Dimensions (L×W×H)：217×194×32.5 mm
• Max Speed：140 Km/h (Manual Mode)
• Maximum Takeoff Altitude：5000 m
• Max Hover Time：Approx. 6 mins (With 6S 1400 battery no load)
• Max Wind Speed Resistance：70 Km/H (Level 4)
• Operating Temperature Range：-10° to 40° C (14° to 104° F)
• Antennas: Single Antenna
• GNSS：N/A

PRE-TUNED & PRE-SETUP:

– Don’t worry about tuning, we did that for you already! A basic PID- and Filter tuning was applied for a great flight experience!

To restore lost tunes or updates, please check our linked article on “Firmware/Factory Dumps”

– Angle-Mode (self balancing level mode) is enabled by default to make sure your first flight doesn’t end in a mess!

Please check our linked article on “How to disable Angle-Mode, activate Acro-Mode”

Spare Parts (Not Included):

• iFlight ProTek35 V1.4 Frame Kit
• Original Props: iFlight Nazgul 3535 Tri-blade CineWhoop Propellers (Set of 4)
• Alternate Props: Gemfan D90 3-Blade Ducted 90mm (3.5″) Propellers (Set of 4)
• Antenna: Short 60mm, Medium 100mm, Long 150mm

Reccomended Batteries (Not Included)

• Value 1100mah: CNHL Black Series 1100mAh 22.2V 6S 100C Lipo Battery

• Lightweight HV 1100mah: GNB Battery 22.8V 120C 1100mAh 6S HV
• Premium 1200mah: Tattu R-Line Version 5.0 22.2V 150C 1200mAh 6S Battery
