Description

The iFlight SH CineLR 7 O4 Frame Kit is engineered for high-speed, long-range flights with maximum durability. Its quick-release side panels simplify maintenance, while the rear-mounted power connector optimizes balance and control. Designed for the DJI O4 Air Unit Pro, it delivers ultra-HD video with prop-free views. With reinforced arms and a sleek, aerodynamic build, this frame ensures smooth, powerful, and crystal-clear FPV experiences in any environment.

Features:

• Quick-release side panels

Provide protection against debris and allow for easy maintenance while ensuring a cleaner setup with no cable entanglement.

• Integrated Action Camera Base Mount

Sleek and integrated design, redefine aesthetics.

• Rear-mounted Power Connector

Optimized weight distribution for improved flight stability and precision.

• Reinforced Arm Base

Strengthened the connection between the arm base and the drone to improve durability.

Specifications:

• Product Name：SH CineLR 7 O4 Frame Kit
• Wheelbase: 334mm
• Frame Dimension: L285*W196*H45mm
• Arm Thickness: 6mm
• Bottom Plate Thickness: 3mm
• Top Plate Thickness: 2mm
• Upper Plate Thickness: 3mm
• Mid-Lower Plate Thickness: 6mm
• Max Flight Stack Height: 20mm
• Max VTX Height: 22mm
• Flight Stack Mounting: 20*20/Φ3mm 30*30/Φ3mm
• Motor Mounting: 19*19/Φ3mm
• VTX Mounting: 25.5*25.5/Φ2mm
• Weight: 336g±5g
• Compatibility: DJI O4 Air Unit Pro/DJI O3 Air Unit

Package Includes:

• 1 x SH CineLR 7 Frame Kit
• 2x IPEX to RP-SMA Antenna Pigtails
• 1 x TPU Set
• 1 x GoPro TPU Base Mount
• 1 x Screw Bag
• 2 x Anti-slip Battery Pad
• 2 x Battery Strap
