iFlight x 2Raw Specter 7 O4 Pro BNF ExpressLRS Diversity 2.4GHz with GPS

Description

Please note we have selected the ExpressLRS 2.4Ghz True Diversity (2x rf chips with 2x antenna) which also has high output 250mW telemetry (to return data to the radio), for other options please contact us [email protected]

The iFlight x 2Raw Specter 7 O4 Pro BNF ExpressLRS is built for elite FPV pilots, combining a robust truss frame, high-performance electronics, and aerodynamic efficiency. Its quick-release shell allows instant access for maintenance, while the 2RAW H7 Thunder flight controller ensures smooth, stable flight. With full-size GPS for precise positioning and an underslung GoPro mount for unobstructed views, this drone delivers exceptional speed, control, and cinematic capability.

Features:

• Shell Quick-release

Access electronics within One click

• Premium Electronics Package

The Spectre is equipped with advanced, high-end electronics, featuring a full-size GPS forrapid GPS lock and the 2RAW H7 Thunder flight controller, which minimizes electrical noise to deliver exceptionally smooth flight performance.

• Easy Maintenance

The Spectre features a unique shell quick-release system that allows for easy one-click opening of the shell, providing full access to the internal electronics.

• Reinforcement Structure

The Spectre incorporates CNC aluminium parts in key areas such as arm ends, internal arm joints, and the GoPro mount. This design simplifies the complex truss structure, allowing for easy assembly while ensuring exceptional strength.

• Truss Design

The Spectre features the tried-and-tested 2RAW truss design for its arms, delivering an unparalleled strength-to-weight ratio while maintaining exceptional torsional resistance.

• Aero Shell

2RAW’s signature aero shell protects the internal electronics from debris and dirt, drastically improving the drone’s aerodynamic performance in the sky. It also features integrated LEDs, allowing users to easily spot their drone in the air.

• Unmatched FOV

With a unique underslung GoPro mounting method, the Spectre enables users to have no props in view from -45 to 45 degrees in both the DJI O4 feed and the GoPro feed.

Specifications:

• Product Name: Specter 7 O4 6S HD
• Geometry: Squashed X
• FC: iFlight Thunder H7 Flight Controller
• ESC: BLITZ E55 4-IN-1 ESC
• Video Transmission: DJI O4 Air Unit Pro
• Frame: 306mm wheelbase
• Motor: XING2 2806.5 1400KV motors
• Prop: GEMFAN 7043*3 propellers
• Dimensions (L×W×H): 232*201*62mm
• Weight: 824±10g (Without Battery)
• Takeoff Weight: Approx. 1309±10g（incl. 6S 3300mAh）
• Max Speed: 150km/h
• Maximum Takeoff Altitude: 7000 m
• Max Hover Time: Approx. 24-25 mins with 6S Lipo 5600mAh battery No Load
• Max Wind Speed Resistance: Level 7
• Operating Temperature Range: -20℃—40℃
• Antennas: Dual Antennas
• GNSS: GPS+SBAS+Galileo+QZSS+Glonass

Video Transmission:

• Product Name: DJI O4 Air Unit Pro
• Image Sensor: 1/1.3-inch
• Lens: FOV: 155°
• ISO: 100-25600
• Video Resolution: 1080p/100fps H.265
• Video Format: MP4, Max Video Bitrate: 130Mbps
• Color Mode: Normal Mode/D-Log M
• Stabilization: RockSteady 3.0+ ; Stabilization function off (When RockSteady is enabled, the shooting angle only supports standard.)
• Live View Quality: 1080P@100fps
• Operating Frequency: 5.170-5.250 GHz  & 5.725-5.850 GHz
• Transmitter Power (EIRP): 5.1GHz＜23dBm(CE)/5.8GHz＜33dBm(FCC)/＜14dBm(CE)/＜30dBm(SRRC))
• Max Video Transmission Range: With DJI Goggles 3/DJI Goggles N3: 15 km (FCC), 8 km (CE), 8 km (SRRC)
• Communication Bandwidth: Max 60 MHz
• Antenna: Dual antennas
• Built-in Storage: 4GB
• Supported SD cards: microSD (up to 512GB)
• Operating Temperature: -10° to 40° C
• Weight: Air Unit (camera module included): Approx. 32 g
• Dimensions: Transmission Module: 33.5×33.5×13 mm (L×W×H)

Package Includes:

• 1 x Specter 7 6S HD BNF
• 1 x Screw Bag
• 1 x Battery Strap
• 1 x Battery pads

Recommended (not included) Batteries:

• General Flying: GNB LiPo Battery 22.2V 100C 2800mAh 6S
• Performance Pack:  GNB Battery 22.2V 120C 2600mAh 6S
• Long Range (lipo): GNB Battery 22.2V 100C 3000mAh 6S
• Long Range (lipo): GNB Battery 22.2V 120C 4500mAh 6S XT90 (note adaptor needed)
• Long Range (li-ion): Auline Li-Ion Battery A45 6S1P 22.2V 4000mAh XT60
• Premium Long Range (li-ion): iFlight Fullsend 6S 4000mAh Li-Ion Battery
• Super Huge Long Range (li-ion): Auline Li-Ion Battery 6S2P 22.2V 8000mAh XT60

Recommended (not included) Spares:

• Alternate Options; HQProp 7X3.5X3 Poly Carbonate Propeller Grey (Set of 4)
• Alternate Option: Gemfan Hurricane 7050 3-Blade Propellers (2 Colours)
