Description
Featuring an ergonomic design, large bright LCD screen in the perfect viewing position, travel adjustable HALL sensor gimbals, a nano size external RF module bay, built-in USB-C Charging, USB-C Data port for updating and playing simulators, rear and top assignable push buttons, scroll wheels, RadioMasters 7 button menu navigation system, headphone audio output, external power source input and a host of RF options the RadioMaster Zorro is set to change the game once again.
Specifications
- Physical Dimensions: 170*159*108mm
- Weight: 350 grams
- Operating Frequency: 2.400GHz-2.480GHz
- Internal RF Options: ELRS OR 4 in 1
- RF Power: ExpressLRS 250mw, 4-in-1: 20dBm max
- Antenna Gain: Folding 2db
- Operational Current: [email protected]
- Operational Voltage: 6.6-8.4v DC
- Control Distance: > 2km @ 20dbm
- Operating system: OpenTX / EdgeTX Compatible
- Control channels: Maximum 16 (Rx dependent)
- Display: 128*64 Monochrome LCD
- Battery: 2 x 18350 (Not included)
- Charging: Built in USB-C Charging
- Gimbal: Hall-effect
- Module Bay: Nano Size (Compatible with TBS Nano Crossfire / Nano Tracer / IRC Ghost)
- Firmware Upgrade: Via USB or SD card
Spares and Batteries (Not Included):
- Batteries:
- Carry Case:
- Gimbals:
Spares and Batteries (Not Included):
- Batteries:
Adam B. (verified owner) –
Comfortable grips and nice display with quick and easy trim settings
Jacob (verified owner) –
Something rattles inside it, but it gets the job done and works well. very comfortable to hold.
Jasper Kueppers (verified owner) –
Absolutely loving this transmitter, it has replaced my TX16S for both my quad and flying wing (ELRS version). Feels great in the hand, works fine for hybrid pinching, and the gimbals are totally fine in contrary to what some online reviewers say. Only thing is that by default the stick tension is quite low, but this can be adjusted. Battery life is good enough, but could be better. It charges very quickly though from USB-C
Nathan C. (verified owner) –
Best gamepad style radio. Well built and easy to use. Also you can get just about every replacement part from Radiomaster which is nice to think about going forward if you broke a switch, cracked the case or screen, etc.
Phillip Inozemtsev (verified owner) –
Feels great in your hands. Enjoying the rubber parts at the back.
Evan Walker (verified owner) –
This controller it’s the perfect size and so smooth massive upgrade for me
Will (verified owner) –
Very nice unit. Just make sure you dont mess around with the settings unless you are very confident. Fantastic price compared to other radios sold at other hobby shops. Plenty of support for the product online too. Fantastic customer service. Will be purchasing from the store again!
Kester Roberts (verified owner) –
I absolutely LOVE this controller! I used to grip my old box controller so tight when doing hair-raising flying. Now flight is comfortable and so enjoyable as the shape conforms to my hands.
Its all the power of the big expensive tx16s yet with a more comfortable and a very reasonable price point!
Jam – packed with features and running EdgeTX.
Worth every penny!
Tai (verified owner) –
So good I purchased another.
Jeremy (verified owner) –
Great radio, takes a bit of tinkering to make EdgeTX do what you want but it’s pretty amazing.
Zahne (verified owner) –
Great radio so far
Logan Watkins (verified owner) –
Great radio. love the feel of it and easy to use.
Bailey W. (verified owner) –
Great feeling radio with so so many features. It’s compact and familiar if you are used to game pad style controllers.
There is quite a bit of setup if your new to edgeTX but plenty recourses and its easy once you get your head around the interface.
xmrmcmemex (verified owner) –
only downside you have to get batteries yourself
Zack Palmer (verified owner) –
Love this thing, awesome firmware and I actually like the basic mono screen, and there’s a surprising amount of telemetry and features. All the switches are easy to reach.
Also you can change the boot sound to the Windows XP startup sound (or any sound)
USB C charging is a bonus, but it’s kinda weird that the data USB C port and power USB C port are seperate, but it’s fine.
My throttle was pretty scratchy when I got it, I had to open it up and lube the friction surface and it improved it significantly.
The manual is pretty useless and you’ll have to Google and watch YouTube videos to set a lot of things up, but the device itself is very competent.
Anonymous (verified owner) –
Comfortable to hold good to start to learn how to fly as can use it either with a drone or asin
